Illustration Details for Pennwest Homes Standard HVAC System For Ranch and Cape Cod Style Homes

Each Pennwest home is designed with a completely self-contained heating and air return system.
   By installing the self-contained heating and air return system at our manufacturing facility:

#1  High Efficiency Gas Furnace – Offers quiet, energy-efficient operation and eliminates the need for a special ventilation chase.
#2  50 Gallon Electric Water Heater – This dual element quick recovery water heater is located closer to areas where it will be used.

#3  Main Return Air Duct – This duct is large and designed to reduce unnecessary air travel to get the air back to the furnace more quickly for optimum performance.
#4  Main Ceiling Return Air Grill – The large return air grill in the ceiling is positioned to allow the furnace to pull the most non-restrictive air in the home for maximum efficiency.
#5  Return Air Duct-work – The flexible duct allows for easy connection and the shortest distance from the ceiling diffuser to the return air system.
#6  Ceiling Return Air Grills – Strategically located throughout the home to provide essential air flow needed to maintain a comfortable environment.
#7  Wall Grills – Wall grills allows air to move freely from room to room without the need to raise interior doors, which is unattractive and reduces privacy.
#8  Fiberglass Duct System – Provides even airflow for maximum comfort throughout the home.
#9  Perimeter Heating Floor Registers – The perimeter duct registers are positioned near the exterior walls to ensure maximum energy efficiency and optimum air flow.
      They are located away from high traffic areas.
#10 Programmable Thermostat – Allows you to choose the temperatures that you are most comfortable at different times of the day and night without manually changing
      it each time. Proper programming maximizes energy efficiency.
#11 Drain Lines – Stubbed only, to be completed on-site by others.
#12 Hot and Cold Water lines – Completely installed system eliminates the need for costly on-site installation.


       * THIS INTERIOR RENDERING IS FOR ILLUSTRATION ONLY AND DOES NOT DEPICT AN ACTUAL PENNWEST HOME. SOME FEATURES SHOWN ARE FOR MARKETING PURPOSES ONLY.


Illustration of Pennwest Homes Standard HVAC System For Ranch and Cape Cod Style Homes using an interior Artist's Rendering

Pennwest Homes Standard HVAC System For Ranch and Cape Cod Style Homes - Also Available as a Printable   Click To Open PDF Document PDF Brochure

   Pennwest homes are set apart from all others in their quality, workmanship, engineering and attention to detail. Combing all of these resources Pennwest homes come standard from the modular home factory with one of the highest quality HVAC systems available in the industry. Other modular home products in the market simply can’t compare their HVAC system to a Pennwest! The Pennwest standard HVAC system is illustrated below using artist’s renderings. Their is a Ranch/Cape Style HVAC System Illustration and a separate Two Story home HVAC System Illustration to cover the wide variety of home styles available. In the illustrations below the entire cooling system is not depicted. Air conditioning is an optional feature available from Patriot Home Sales. The Pennwest HVAC System is designed to quickly accept the outside Energy Star rated Air Conditioning Unit. The furnace, blower and duct work are designed with air conditioning in mind. As always if you need additional information please email us.

Illustration of Pennwest Homes Standard HVAC System For Two Story Homes using an interior Artist's Rendering

Pennwest Homes Standard HVAC System For Two Story Homes - Also Available as a Printable   Click To Open PDF Document PDF Brochure

Illustration Details for Pennwest Homes Standard HVAC System For Two Story Homes

Each Pennwest home is designed with a completely self-contained heating and air return system.
   By installing the self-contained heating and air return system at our manufacturing facility:

#1  High Efficiency Gas Furnace – Offers quiet, energy-efficient operation and eliminates the need for a special ventilation chase.
#2  50 Gallon Electric Water Heater – This dual element quick recovery water heater is located closer to areas where it will be used.

#3  Main Return Air Duct – This duct is large and designed to reduce unnecessary air travel to get the air back to the furnace more quickly for optimum performance.
#4  Main Ceiling Return Air Grill – The large return air grill in the ceiling is positioned to allow the furnace to pull the most non-restrictive air in the home for maximum efficiency.
#5  Return Air Duct-work – The flexible duct allows for easy connection and the shortest distance from the ceiling diffuser to the return air system.
#6  Ceiling Return Air Grills – Strategically located throughout the home to provide essential air flow needed to maintain a comfortable environment.
#7  Wall Grills – Wall grills allows air to move freely from room to room without the need to raise interior doors, which is unattractive and reduces privacy.
#8  Fiberglass Duct System – Provides even airflow for maximum comfort throughout the home.
#9  Perimeter Heating Floor Registers – The perimeter duct registers are positioned near the exterior walls to ensure maximum energy efficiency and optimum air flow.
      They are located away from high traffic areas.
#10 Programmable Thermostat – Allows you to choose the temperatures that you are most comfortable at different times of the day and night without manually changing
      it each time. Proper programming maximizes energy efficiency.
#11 Drain Lines – Stubbed only, to be completed on-site by others.
#12 Hot and Cold Water lines – Completely installed system eliminates the need for costly on-site installation.


       * THIS INTERIOR RENDERING IS FOR ILLUSTRATION ONLY AND DOES NOT DEPICT AN ACTUAL PENNWEST HOME. SOME FEATURES SHOWN ARE FOR MARKETING PURPOSES ONLY.
